Product Description:

This ELK Alarm Engine 16-Zone Input Expander is a highly flexible and powerful component for your security system’s enhancement, which is aimed at adding more signals to your setup. It has zone 0-15 EOL resistor supervised hardwire zones for efficient monitoring so that the system is highly reliable. The expander has an externally accessible Form C relay output for the expansion of other functions and control. It has a DC power and battery connections keep power constant, making it possible for the device to remain functional during a power outage. Using a 4-wire data bus, the expanders make installation of this product quite easy and enhance the communication between the main alarm panel and the expander. As for the connections, there are plug-in terminal strips that make connections fast, effective, and secure. With built-in LED indicators for status and diagnostics provides immediate visual feedback on performance.

The ELK Alarm Engine 16-Zone Input Expander has an onboard EOL bus termination jumper that makes the signal line stronger and immune to considerable interferences. For more Elk products, please visit this page.

Main Features:

• 16 EOL Resistor Supervised Hardwire Zones
• DIP switch selectable EOL resistance values (1.0K, 2.2K, or 3.3K)
• 1 Formin.C” Relay Output
• DC power & battery connections
• Operates on the 4-Wire Data Bus
• Plug-In Terminal Strips
• Status and Diagnostic LED
• On-Board EOL Bus Termination Jumper
• Vertical Mounting using ELK-SWG Glides(included)

Installation Instructions:

*Before making any wiring connections, TURN THE E27 MASTER POWER SWITCH OFF

• Data Bus: CAT5 or CAT6 wire (4 pairs, 8 conductors) is highly recommended for all data bus cables and the extra wires may be required for data return paths where multiple home runs or devices are installed. Use 4 conductors to connect terminals BUS +12V, Data A, Data B, and Neg from control to terminals +12V, A, B, and Neg on the expander.
