The DSC NEO Wireless Door Window Sensor with Aux input is installed on common intrusions points such as windows and doors to provide perimeter protection of the premise. It is also designed to communicate with the security system to report openings and closings of doors & windows. Known for its versatility and reliability, this sensor is an easy-to-install device ideal for a wide range of environments.

The sensor also has a visible link quality LED indicator on the contact that lets the installer choose the optimal location for installation, eliminating the effort of going back and forth to the keypad. Additionally, device configuration is quick and easy with no hardware switches or need to re-open devices. You can handle all device configuration settings on the system keypad.

This sensor also features an auxiliary input that you can use to easily connect a standard hardwired contact. While you can also configure the auxiliary input to be Normally Open, Normally Closed, or Single End-of-Line. This feature is useful in installations where space is of a premium and it is difficult to mount the magnet within the maximum allowable gap of the contact.

Furthermore, the sensor is also compatible with DSC Powerseries Neo or DSC Iotega as well as Qolsys Power G.

DSC NEO Wireless Door Window Sensor with Aux input Features:

• Selectable operation of auxiliary input as NO, NC or EOL supervision
• Visible link quality indicator shown on device
• Case and wall tamper
• Available in either white or brown to blend into any décor
• User-selectable operation of auxiliary input as NC or EOL
• Prolonged battery life (8 years with typical use)
• Back tamper switch options (MC-302E T PG2 model)

Specifications:

• Dimensions: 81 x34 x 25mm (3.40 x 1.25 x 1in)
• Battery Life: up to 8 years (typical use)
• Battery Type: 3V Lithium Battery
• Gap: 1/4″
• Weight: 53g (1.9oz)
• Operating Temperature: -10°C to 55°C (14°F to 131°F)
