Product Description:

This Altronix Switching Power Supply/Charger converts a 115VAC 60Hz input into two (2) individually PTC-protected 12VDC or 24VDC outputs. With its advanced switching technology, this power supply delivers a constant and steady output voltage that is suitable for a wide range of applications, including security, access control, and surveillance systems. It also has a Fail-Safe/Fail-Secure lock output that can provide options if there is no power applied to the system. This Altronix Switching Power Supply/Charger is built to withstand harsh environmental conditions and is capable of operating in temperatures ranging from 0ºC to 49ºC. This power supply also has a UL 294 (access control) certificate that is used to evaluate safety and ensures that the product will operate reliably without hazardous conditions.

It also offers more ampere than Altronix Access Control Power Supply which also converts 115VAC 50/60Hz input into two individually PTC-protected 12VDC or 24VDC outputs. Note: This power supply/charger needs a power cord to work.

Product Specification:

• Input: 115VAC, 60Hz, 0.6A.
• Access control trigger input
• Output: 12VDC or 24VDC selectable outputs
• 1.75A supply current
• Two (2) Class 2 Rated power limited outputs
• Fail-Safe/Fail-Secure lock output (switched)
• Auxiliary power output (unswitched)
• PTC-protected outputs, rated @ 2.5A
• Short circuit and thermal overload protection
• AC input and DC output LED indicators
• Temperature: Operating 0ºC to 49ºC (32ºF to 120ºF), Storage – 20ºC to 70ºC ( – 4ºF to 158ºF)
• Dimensions: 8.5” x 7.5” x 3.5”
