Product Description:

This 12-Channel Video Control Panel with PoE is a high-performance and effective surveillance management system for professional security camera installations. The advanced control panel makes the video system deployment easy and offers centralized video management and integrated Power over Ethernet (PoE) support for IP cameras, which allows installers to power and connect compatible IP cameras with one device. It is used in commercial buildings, retail stores, warehouses, offices, schools, and residential security systems. The multi-channel design allows for up to 12 video channels, and is great for medium to large-scale security camera systems that want to be connected reliably and managed centrally. Plug-and-play PoE capability helps save installation costs and provides support for powering compatible network cameras without requiring a separate power supply or extra cabling. Its compact and professional enclosure allows for clean installations in structured wiring cabinets, server rooms, security closets, and commercial monitoring environments.

The 12-Channel Video Control Panel with PoE offers scalable performance, reliable power delivery, and professional video surveillance support for new installations or system upgrades. If you are looking for security cameras for your system, feel free to look here in our shop.

Main Features:

• POE Power or 12V DC Power
• 12 Normally Open or Closed Alarm Inputs
• 12 Camera Channels
• Turn Camera Analytics into Alarm Reporting Zones
• Converts Video Analytics Alarm Signals for Central Station Response
• Bind Alarm Inputs and Camera for Video Events
• Pair Cameras with Existing Alarm Panel Zones
• 4 – 5Amp Normally Open and Closed Controllable Relay Outputs
• 1 – Arming Input for Key Switch Arming from Traditional Alarm Systems
• Remote Talk-Down Capability to Support IP Speakers and an Analog Line-level Audio output

Specifications:

• Audio Output: (3.5mm) Line output (non-amplified) & IP Audio
• USB Ports: 2 x USB2.0 type A + 2 x USB3.0 type A
• Channel Zones: Digital Input Indicators (Red-Alarm, Off-Normal)
• Ethernet: RJ-45 10/100/BASE-T Connection
• Encryption/Security: TLS/SSL (Secure Socket Layer)
• Power Requirements: 12v DC / PoE IEEE 802.3af class4
• Power Consumption:
  • DC: 800m Amps Peak
  • PoE: 10.5W Peak
• Product Dimension: 225mm x 96mm x 35mm
• Weight: 350g (0.8lb)
