Wireless Door Interface Unit

(1 customer review)

$160.00

The Wireless Door Interface Unit works as a chime, dry relay output, or both for common applications while also for switching power to a maglock or a door strike. Furthermore, this interface is an add-on product to the Wireless Intercom Door System allowing the ability to add remote door release capabilities with selectable chime tones and volume (door lock hardware not included). Lastly, ideal for office environments, retail stores, as well as other light commercial and residential settings.

SKU: 2614 Category:
Description

Wireless Door Interface Unit Description:

The Wireless Door Interface Unit works as a chime, dry relay output, or both for common applications while also for switching power to a maglock or a door strike. Furthermore, this interface is an add-on product to the Wireless Intercom Door System allowing the ability to add remote door release capabilities with selectable chime tones and volume (door lock hardware not included). Lastly, ideal for office environments, retail stores, as well as other light commercial and residential settings.

You can also check out our other intercom products that may fit into your security system.

Wireless Door Interface Unit

Key Features:
  • Hardwired
  • Sub1GHz connection to the Wireless Intercom Door Station
  • While external output to electric strike or maglock
  • Chimes at the visitor event
  • 5 selectable chime tones available
  • 3 level or chime volumes or muted mode
  • Selectable output duration time
  • Wall mount
Product Specifications:
  • Frequency: 916Mhz
  • Power: 10V to 24V AC/DC
  • Chime Tone: *5 types selectable
  • Chime Volume: Approx. 80 dB max. 3 levels & mute
  • Relay Output Duration: *1/5/10/30/60 sec. selectable
  • Relay Output Rating: 1C relay, 1 A max. 50 V AC/24 V DC
  • Operating Temperature: 0°C to 40°C (-32°F to 104°F)
  • Operating Humidity: <90% Rh (no condensation)

Please check out our YouTube Channel for more information.

Reviews (1)

1 review for Wireless Door Interface Unit

  1. Michael Donahue

    Works great in my office.
