Description of Qolsys Encrypted Hardwire Module:

Qolsys Encrypted Hardwire Module allows you to encrypt and connect up to 16 hardwired zones wirelessly while to the Qolsys Panel. In addition, since it automatically learns the sensor’s resistor values, it’s easy to install and the perfect solution for existing systems or new construction. The product includes a small enclosure that is designed to be mounted into an existing can, it has a place to connect a backup battery charging, 500mA of 12volt auxiliary power, an onboard siren relay, built-in status LED for each zone, and support for up to 10 two-wire smoke detectors. Furthermore, if you are looking for fire integration, we have the Qolsys Pre-Wired Fire Module available here.

If you do not have an existing can to mount this inside of you will want to order either the power g version or the large enclosure version. Also, you will want to add a backup battery to this if you do not have one already.

Features:

• Encrypted S-Line sensor technology protects signals sent to the Qolsys Panel while still providing support for legacy 319.5 systems
• LED lighted zones for ease of “learn-in” installation/troubleshooting
• EOL resistor learning supports 1-10K Ohm resistors.
• Up to 500 Milliamps of power for hardwired motion detectors, glass break detectors, and/or sirens
• Charging circuit for backup battery fully supervised with power outage recovery.
