The Mid-range HD-TVI IR Turret Camera 131ft 2.1MP 3.6mm is the camera you need for high quality images. This series of camera adopts new generation sensors with high sensitivity and advanced circuit design technology. It also features high resolution, low image distortion on, and low noise, which makes it suitable for surveillance system and image processing system.

But if this isn’t what you’re looking for, please take a look at our other HD-TVI cameras.

Features:

• High performance CMOS sensor
• High resolution
• Low illumination
• OSD menu, parameters are configurable
• Support auto white balance, auto gain control, electronic shutter control
• SMART IR mode
• Unit transmission control
• Advanced 3-axis design meets different installation on requirements

Mid-range HD-TVI IR Turret Camera 131ft 2.1MP 3.6mm Installation
Steps:

1. Drill the screw holes and the cable hole according to the drill template.
2. Fix the mounting base to the ceiling with the supplied screws.
3. Route the cables to the cable hole and connect the corresponding power cable and video cable.
4. Secure the camera to the mounting base.
5. Fix the enclosure to the camera to complete the installation.

Specifications:

• 1 / 2.7” Sensor
• Effective Pixels: 1930(H)*1088(V)
• Min. Illumination: 0.1 Lux @(F1.2,AGC ON), 0 Lux with IR
• Shutter Speed: NTSC:1/30 s(PAL:1/25 s) to 1/50,000s
• Lens: 3.6mm
• Day & Night
• The angle of View: 90°
• HD Video Output NTSC: [email protected]/PAL: [email protected]
• S/N Ratio: More than 52dB
• Working Temperature/Humidity : -40 °F – 140°F (-40 °C – 60°C), Humidity 90% or less (non-condensing)
• Power Supply: 12V DC
• Power Consumption: Max. 3W
• Weather Proof Ratings: IP66
• IR Range: Up to 131ft (40m)
• Dimensions: φ5.0″x4.0″ (φ126.7 x 102.1mm)
• Weight: 1.1lb (500g)
