Description:

The GE Interlogix Compatible Temperature Range Sensor is pre-set to alert the system when the temperature drops below 40F/5C or when it rises above 100F/37C degrees. High and low temperature alerts are indicated to the alarm panel as 2 distinct loops/IDs. The resolution temperate range sensor is compatible with GE alarm systems, with long range performance and long battery life.

GE Interlogix Compatible Temperature Range Sensor Features:

• Compatible with GE alarm systems and Elk M1XRFEG receivers
• Alerts alarm panel when temperature drops to 40F/5C or rises to 100F/37C
• Low battery indication
• Strong, reliable RF signal
• Crystal mode
• 8-10 year batter life on CR123A battery
• Dimensions: 3.3 x 1.4 x 1.1 inches

 Instructions

• Battery “+” faces towards spring.
• Enrolling:
• Freeze (1st ID): enrolled by tamper switch. (This ID is on a label on the battery bucket.)
• Overheat (2nd ID): enrolled by holding down tamper while installing battery. (This ID is not on a label.)

 Operation

• Freeze (1st ID)
• Alarm: when room temperature drops below 45F.
• Tamper: when cover is opened.
• Supervisory: every hour.
• Overheat (2nd ID)
• Alarm: when room temperature rises above 100F.
• Tamper: when cover is opened.
• Supervisory: every hour.

 Specifications

• Freeze Alarm Temp: 45F +/- 2F
• Freeze Restore: when temp increases 4F from alarm
• Overheat Alarm Temp: 100F +/- 2F
• Overheat Restore: when temp decreases 4F from alarm
• Mounting hardware: # 4 or #6 screws
• Replacement Battery: CR123A 1550 mAH
• Temperature Range: 0F to 120F
• Housing dimensions: 3.3×1.4×1.1 inches
