Product Description:

This Alarm.com Universal Communicator is designed to bring flexibility, control, and reliability to any compatible alarm system. It works with a wide range of alarm panels, so you don’t have to worry about being locked into one brand. It supports LTE, EDGE, and GPRS for secure, redundant communication. With its Smart Connector technology, installers can connect certain alarm panels as a virtual keypad for simpler setup and operation. Plus, with key zone switching, users can conveniently arm or disarm the system or even specific zones directly from the Alarm.com mobile app. The Alarm.com Universal Communicator also provides remote software updates and access to control panels, reducing the need for on-site service visits. And since Alarm.com built it with the future in mind, the communicator supports integration with Alarm.com cameras and home automation.

For more options, feel free to check our available Alarm.com devices here in our shop.

Main Features:

• Panel Agnostic
• T&T Global Roaming SIM card
• Dial Capture DTMF – (CID/SIA Events)
• Remote arm/disarm through Keyswitch Zone
• Remote firmware update capability for the communicator module
• Smart Connector (multiple partitions, Armed Stay, Away, Night)

Specifications:

• Configuration: LTE, EDGE, GPRS
• Protocols supported: SIA, ContactID, XML
• Transmission security: AES encryption
• Serial interface: RS232 / RS485 transmission speed up to 115200bps
• LED status function: 4 LEDs (cellular signal level, device status, DTMF communication)
• Voltage Supply: 13,8VDC (acceptable: 12-14VDC)
• Temperature range: -10ºC to 55ºC, 14ºF to 131ºF
• Humidity range: 5% to 93% (without condensation)
• Dimensions of PCB: 102mm x 73mm

Please check out our YouTube Channel for more information.
