Product Description:

The Alarm.com Smart Chime Bracket is a dual-function device designed to enhance the capabilities of Alarm.com video doorbell cameras. This versatile unit acts as both a wireless digital doorbell chime and a 2.4 GHz Wi-Fi extender, making it an essential component for ensuring reliable network connectivity and seamless audio notifications in a smart home security setup.

Key Features and Benefits

1. Wireless Doorbell Chime:

The ADC-W115C serves as a customizable doorbell chime that integrates effortlessly with Alarm.com video doorbells. When a visitor presses the doorbell, the Smart Chime produces an audible alert, allowing you to hear the doorbell ring from various locations within your home. This is particularly useful if your existing in-home chime is incompatible or non-functional. The chime volume is adjustable, and you can select from various tones to suit your preferences​.

2. Wi-Fi Extender:

The Smart Chime also functions as a robust Wi-Fi extender, operating on the 2.4 GHz frequency band. It enhances the range and reliability of your Wi-Fi network, ensuring that your video doorbell and other Alarm.com devices maintain a strong and stable connection. This is crucial for streaming video feeds and receiving real-time alerts without interruptions.

3. Easy Installation and Setup:

Installation is straightforward. The device plugs into a standard, unswitched electrical outlet. It can be added to your existing network using either Wi-Fi Protected Setup (WPS) or Access Point (AP) mode. Once connected to the network, the Smart Chime is added to your Alarm.com account through a simple pairing process, typically managed via the Alarm.com mobile app or dealer portal.

4. Remote Management and Troubleshooting:

The ADC-W115C supports remote management, allowing users and technicians to configure and troubleshoot the device remotely via the Alarm.com platform. This ensures that any issues can be quickly resolved without the need for physical interaction with the device, providing convenience and peace of mind​.

Specifications

• Wi-Fi Connectivity: Supports 802.11 b/g/n protocols on the 2.4 GHz band with WPA2 security, ensuring secure and reliable connections.
• LED Indicators: The device features four LED indicators to provide visual status updates:
  • Power: Indicates whether the device is powered on or off.
  • Router: Shows the connection status to the local network and the internet.
  • Devices: Indicates the connection status of paired devices.
  • WPS: Displays the status of the WPS pairing process.
• Buttons: Equipped with WPS and Reset buttons for easy setup and troubleshooting.
• Antennas: Includes two antennas to enhance Wi-Fi signal strength and coverage.
• Chime Specifications: Features a 1.5 W speaker with a maximum sound level of 77 dB, providing clear and audible alerts throughout the home.
• Operating Conditions: Designed to operate in temperatures ranging from 32°F to 104°F (0°C to 40°C) and humidity levels between 10% and 90% (non-condensing)​.
• Dimensions:
  • With antennas: 5.0 x 1.0 x 2.1 inches (12.7 x 13.0 x 5.4 cm)
  • Without antennas: 3.3 x 3.3 x 2.1 inches (8.5 x 8.5 x 5.4 cm)

Installation Process

1. Plug In: Insert the Smart Chime into a standard, unswitched electrical outlet near your router initially for setup purposes.
2. Connect to Wi-Fi: Use WPS by pressing the WPS button on your router followed by the WPS button on the Smart Chime, or use AP mode for a manual setup through a web browser.
3. Add to Alarm.com Account: Use the Alarm.com app or dealer portal to add the Smart Chime to your account, following the on-screen instructions to complete the pairing process.
4. Move to Desired Location: Once setup is complete, you can move the Smart Chime to an optimal location, typically mid-way between your router and the video doorbell to maximize Wi-Fi coverage and chime audibility​.

Compatibility

The ADC-W115C is compatible with a range of Alarm.com video doorbells, including but not limited to:

• ADC-VDB770
• ADC-VDB105X
• ADC-VDB106X
• ADC-VDB101
• ADC-VDB102

This makes it a flexible addition to various smart home security setups, ensuring consistent performance and extended Wi-Fi coverage across multiple devices.

Conclusion

The Alarm.com Smart Chime (ADC-W115C) is a valuable asset for any home using Alarm.com video doorbells. It provides both a reliable Wi-Fi extension and an effective auditory notification system, ensuring that you stay connected and informed at all times. Its easy installation, customizable features, and seamless integration with the Alarm.com ecosystem make it an excellent choice for enhancing your home security setup.
